Description

LAUDA Loop 100 is a state-of-the-art thermoelectric circulation thermostat designed to deliver precise and reliable temperature control for viscosity measurements. With its revolutionary Peltier technology, this system is an ideal solution for modern laboratories and industrial environments that require eco-friendly, efficient, and accurate temperature management. Compact, lightweight, and versatile, the LAUDA Loop 100 meets the diverse needs of various industries, from research to quality control.

Key Features

• Versatile Heating and Cooling: Capable of both heating and cooling within the same unit, providing flexibility for a wide range of testing scenarios. Operates in a voltage range of 100 – 240 V, 50/60 Hz, and includes an RS 232-interface for added convenience.
• Temperature Control and Stability: Maintains a working temperature range of 4°C to 80°C, with a temperature stability of ±0.1°C for consistent, accurate results.
• Quiet, Low-Vibration Performance: Operates quietly and with minimal vibration, making it suitable for any laboratory or industrial environment.
• Safe and Reliable Operation: Integrated safety features, such as a button lock, auto-start, and temperature limit warning, ensure worry-free use in any setting.

Why choose the LAUDA LOOP 100?

• Advanced Peltier Technology:
  Harnesses cutting-edge thermo-electric technology for precise and stable temperature control without the need for refrigerants, making it an eco-friendly solution.
• Compact and Lightweight Design:
  Space-saving and portable, the LAUDA Loop 100 fits easily into any lab setting without sacrificing performance. Its dimensions (175 mm W x 301 mm D x 266 mm H) make it an ideal choice for laboratories requiring flexibility.
• Energy Efficiency:
  A power-regulated ventilator fan ensures high energy efficiency, especially during partial-load operations, resulting in reduced operational costs and a smaller environmental footprint.
• User-Friendly Interface:
  With simple 3-button controls and an OLED display, operating the LAUDA Loop 100 is intuitive and easy. Seamless integration with DV360 software further enhances usability and control.
• Versatile Applications:
  The LAUDA Loop 100 is compatible with a variety of water-jacketed DV instruments such as Cone/Plate, Enhanced UL Adapter, Small Sample Adapter, and DIN Adapter, making it suitable for a wide range of laboratory applications, including research, sample preparation, and quality assurance.

Specifications

• Working Temperature Range:
  • 4°C to 80°C
• Temperature Stability:
  • ±0.1 K
• Heater Power:
  • 0.2 kW
• Cooling Output (at 20°C):
  • 0.12 kW
• Power Consumption:
  • 0.24 kW
• Pump Pressure Max:
  • 0.8 bar
• Pump Flow Max (Pressure):
  • 2.6 L/min
• Filling Volume Max:
  • 0.26 L
• Dimensions (WxDxH):
  • 175 mm x 301 mm x 266 mm
